Technics Grand Class SU-GX70 Bluetooth & Network Audio Amplifier
Specifications
Dimensions (W x D x H) 430 x 368 x 98 mm
Weight Approx. 6.6 kg
EAN 5025232932948
Chromecast built-in Yes
AirPlay 2 Yes
Bluetooth® (Supported codecs) Yes (AAC, SBC)
Tuner DAB/DAB+/FM
Output power 40W+40W at 8 Ohms(1kHz,T.H.D.1.0,20kHz LPF)
80W+80W at 4 Ohms (1kHz,T.H.D.1.0,20kHz LPF)
Load impedance 4Ω-16Ω
Frequency response PHONO (MM): 20Hz - 20kHz (RIAA DEVIATION ±1dB, 4Ω)
LINE: 20Hz - 40kHz (-3dB, 4Ω)
DIGITAL: 20Hz - 80kHz (-3dB, 4Ω)
Input sensitivity / Input impedance PHONO (MM): 2.0 mV / 47 kΩ
LINE: 200 mV / 23 kΩ
Analogue input terminals Line x 2
Phono (MM) x 1
Digital input terminals Optical digital x 2
Coaxial digital x 1 USB-A x 1 USB-B x 1
Analogue output terminal Pre-out x 1
Digital output terminal HDMI ARC
Headphone output Yes, Stereo φ6.3 mm
USB-A USB 2.0 High-speed
USB Mass Storage class
iPod/iPhone/iPad (USB-A) No
PC (USB-B) USB 2.0 High-speed
USB Audio Class 2.0, Asynchronous mode
DSD control mode (USB-B) ASIO Native mode, DoP mode
MQA decoder Yes
LAN (DMR)
WAV FLAC DSD AIFF ALAC AAC MP3
Ethernet interface LAN (100BASE-TX/10BASE-T)
WiFi IEEE 802.11a/b/g/n/ac/ax
2.4 GHz band / 5 GHz band
Power supply AC 220 V - 240 V, 50/60 Hz
Power consumption 63 W
