Features

• New to the Radius Range - ultra compact dedicated centre speaker
• New Dual C-CAM^® bass drivers with C-CAM tweeter in MTM style configuration - Radius features all new bass drivers with concave cone profiles, introduced by our top-of-the-range Platinum speakers and applied subsequently to Gold GX.  Extensive research and FEA modelling have allowed us to perfect the relationship between the new radiating diaphragm and its motor design, introducing larger motor sizes and voice coils for increased excursion, higher power capability and reduced distortion.
• New C-CAM gold dome tweeter - optimised to deliver the finest and widest performance within the compact Radius cabinets. It benefits from a more efficient rear-venting design, releasing air trapped and compressed at the back of the tweeter dome, and guiding it around the drive assembly to a rear-loading chamber.
• HiVe^®II port design - Straight from Platinum’s design blueprint, the HiVe reflex port makes its Radius debut. It’s shaped to have the same effect on airflow as a gun-barrel on a bullet. Rifled grooves inside the port help to accelerate the flow and reduce turbulence, so air moves in and out of the port more efficiently, for a faster more dynamic bass response.
• Single through-bolt driver fixing provides mechanical de-coupling and enhanced mid-band clarity and resolution. The through-bolts also act as rigid cross bracing to give a very solid non-resonant cabinet.

  Tech Specs

  - Frequency Response: 60 Hz — 35 kHz
  - Sensitivity (1W@1M): 86 dB
  - Nominal Impedance: 6 ohms
  - Power Handling (RMS): 100 W
  - System Power Handling (RMS): 150 W
  - Recommended Amplifier Requirements: 40 — 150 W
  - Maximum SPL:106 dBa
  - Bass reflex - Rear ported
  - Drive Unit Complement
  - 2 x 4" (100 mm) C-CAM cone bass/mid driver
  - 1 x 1" (25 mm) C-CAM Gold Dome tweeter
  - Impedance: (ohms) 6
  - Power Rating: (Watts) 100
  - Dimensions: WxDxH (mm) 330 x 140 x 125
  - nWeight: (KG) 3.6
