Hana SH MKII High Output Moving Coil Cartridge
The new high output SH MK II MC cartridge has upgrades to enhance both the musical performance, and also to offer greater value at the S Series price point. A new tapered Aluminum cantilever with increased rigidity offers a remarkable improvement in transferring groove modulation from the vinyl record to the cartridge generator. The S Series Mk II indeed features many higher specified parts, advanced materials, and unique technical processes, drawn from Hana’s higher-priced elite cartridge models, furthering the Hana “brilliant and gorgeous” sound.
Critical parts, including the Yoke, Pole-pieces, and gold Terminal pins are cryogenically treated for a more natural sound. An improved non-resonant body shape, modeled after the Hana M Series, is damped with a matte Soft Feel Black elastomeric resin paint, and features a brass top cap plus integral threaded mounting of cartridge. The heavier Mk II cartridge offers better coupling, improving bass and dynamics; and with expanded compatibility to a wider range of tonearms. The SH MK II generator, follows the Umami Blue and M Series cartridge designs; incorporating an Alnico magnet and cross-coil design, using high purity 30-micron copper wire with a 130Ω impedance, for improved signal to noise, and reduction of moving mass. These improved design features offer higher resolution and traceability, optimizing performance when used with MM phono stages.
Specifications
Colour Black
Cartridge Type High Output Moving Coil
Cartridge Body Composite
Cantilever Tapered aluminium
Stylus Nude diamond Shibata
Magnet Alnico
Output Voltage 2 mV @ 1 kHz, 5 cm / sec
Channel Separation 28 dB @ 1 kHz
Channel Balance <1.5 dB @ 1 kHz
Frequency Response 15 Hz – 32 kHz
Compliance 10 mm / N
Impedance 130 Ω
Recommended Loading 47 kΩ
Tracking Force 2 g
Weight 8.6 g
